SPECIFICATIONS

1/2 "*3/32"*46T 7-speed ED Tooth Plate: Shimano 7-Speed

Battery: 60V 27.5Ah Battery (Lithium 18650 Cells)

Bike Height: 45.3" (115cm)

Bike Weight: ≥88lbs (with Battery) (≥40kg)

Brakes: Double Piston Oil Brake, Equipped with 180mm Stainless Brake Disc

Brand Name: COSWHEEL

Certification: ce

Chain: 7-speed Anti-rust, 1/2" * 3/32"

Charger: 60V5A Charger

Charging Time: 3.5-8.0 Hours

Controller: 60V 35A

Crank: 1/2 "*3/32"*46T 7-speed ED Tooth Plate

Display: Easy Read LCD Display

Energy: 1650Wh

Folded: No

Frame: Hydroformed Triple-Butted 6061-T6 Aluminium Alloy

Frame Material: Aluminum Alloy

Front Light: Classic Angel Eye Headlight, 120 LUX

Front Suspension: 20" Shoulder Shock Absorbing, 80mm Travel

Handlebar Width: 26.4" (67cm)

Handlebars: Sand Black 31.8*660

Max Speed: >50km/h

Maximum Load: 330lbs (150kg)

Model Number: CT20S

Motor: 60V Peak 2000W (Rated 1500W) Brushless Rear Hub Motor 120N.m

Overall Size: 70.9" * 26.4" *45.3" (180*67*115cm)

Package Size: 59.4" * 14.2" * 35.4" (151*36*90cm)

Pedal: Aluminum Alloy Pedal, with Reflect-light, Axis 9/16 x2

Pedal Assist: 5 Levels

Power Supply: Lithium Battery

Range: 55+miles (88km) in Class-2 throttle-only mode (pure electricity); 100+miles (161km) in Class-1 PAS (pedal assist)

Range per Power: > 60 km

Rated Passenger Capacity: Two Seat

Rear Light: LED

Rear Suspension: 180mm Travel

Seat Height: 33.4" (85cm)

Sensors: Speed Sensor

Style: Standard Type

Suitable Height: 5'1" - 6'5"

Throttle: Grip Twist Throttle (Old) / Thumb Throttle (New)

Tires: Off-road Tire 20" * 5.0" IA-2149 with AV+Lining

Top Speed: 65km/h-80km/h

Voltage: 60 V

Wheel Size: 20“

Wheelbase: 45.3" (115cm)

Our Advantages

1. Coswheel was established in 2015, focusing on developing high-quality and high-performance electric self-propelled vehicles Having the most experienced and top-notch electric bicycle designers, all models are independently designed and have design expertise.

2. We have a complete research and development, manufacturing, and sales system, providing a large number of orders to customers worldwide and gaining unanimous recognition and favor. Customizable products can be tailored to customer needs.

3. The main goal is to provide excellent cycling experience for riders, whether you are commuting, exploring, or RV in the city Travel or mountain sports. Advocate for a low-carbon lifestyle and create a cleaner and greener.Follow our store, and enjoy the best service and prices.

Overseas warehouse

1. European inventory: takes about 3-10 days arrive.

2. USA inventory: takes about 3-7 days arrive.

Packing list：

Electric bicycle*1

Battery *1

Multi-function tool*1

Charger*1

Pedal*2

Gift:Mudguard*2

Specifications

Top Speed: Class 2/3,28+ Mph (45+Km/h); Off-road Mode +++(60V)

Range: 55+miles (88km) in Class-2 throttle-only mode (pure electricity); 100+miles (161km)in Class-1PAS (pedal assist) Motor: 60V Peak 2000W (Rated 1500W) Brushless Rear Hub Motor 120N.m

Battery: 60V 27.5Ah Battery (Lithium 18650 Cells)

Energy:1650Wh ·Front Suspension:20" Shoulder Shock Absorbing,80mm Travel

Rear Suspension:180mm Travel

Brakes: Double Piston Oil Brake, Equipped with 180mm Stainless Brake Disc

Tires:Off-road Tire 20"* 5.0" IA-2149 with AV+Lining

Throttle: Grip Twist Throttle (Old) / Thumb Throttle (New)

Charger:60V5A Charger

Charging Time: 3.5-8.0Hours

Display: Easy Read LCD Display

Controller: 60V 35A

Front Light: Classic Angel Eye Headlight, 120 LUX

Rear Light: LED

Pedal Assist: 5Levels

Sensors: Speed Sensor

Frame: Hydroformed Triple-Butted 6061-T6 Aluminium Alloy

Pedal: Aluminum Alloy Pedal, with Reflect-light, Axis 9/16 x2

Crank: 1/2“*3/32"*46T 7-speed ED Tooth Plate

Rear Derailleur: Shimano 7-Speed

Chain:7-speed Anti-rust, 1/2"* 3/32"

Handlebars: Sand Black 31.8*660

Suitable Height:5'1"- 6'5"

Seat Height: 33.4"(85cm)

Bike Height:45.3"(115cm)

Wheelbase: 45.3"(115cm)

Handlebar Width:26.4"(67cm)

Bike Weight: ≥88lbs (with Battery) (≥40kg)

Maximum Load: 330lbs (150kg)

Safe Load: 265lbs (120kg)

Overall Size: 70.9"*26.4" *45.3"(180*67*115cm)

Package Size: 59.4"*14.2"* 35.4" (151*36*90cm)
